SRR4028-4R7Y

BOURNS  SRR4028-4R7Y  电感, 4.7uH, 1.55A, 30%, SMD

4.7 µH 屏蔽 绕线 器 1.55 A 70 毫欧最大 1919（4848 公制）

立创商城:
4.7uH ±30% 1.55A 70mΩ

得捷:
FIXED IND 4.7UH 1.55A 70MOHM SMD

贸泽:
Fixed Inductors 4.7uH 30% SMD 4028

e络盟:
功率电感SMD, 4.7 µH, 1.55 A, 屏蔽, 1.3 A, SRR4028 Series, 4.8mm x 4.8mm x 2.8mm

艾睿:
Make any circuit look clean and compact using this power SRR4028-4R7Y surface mount inductor from Bourns. This SMD inductor has an operating temperature range of -40 °C to 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. It has an inductance of 4.7u H. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 55MTyp Hz. This product is 5 mm long, 3 mm tall and 5 mm deep. This device utilizes wirewound technology. This SMD inductor has a maximum DC current of 1.55 A with a maximum resistance of 70m Ohm.

安富利:
Ind Power Shielded Wirewound 4.7uH 30% 100KHz 8.12Q-Factor Ferrite 1.55A T/R

Chip1Stop:
Ind Power Shielded Wirewound 4.7uH 30% 100KHz 8.12Q-Factor Ferrite 1.55A T/R

Newark:
# BOURNS  SRR4028-4R7Y  Surface Mount Power Inductor, SRR4028 Series, 4.7 µH, 1.55 A, 1.3 A, Shielded, 0.07 ohm

MASTER:
Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 8.12Q-Factor Ferrite 1.55A 70mOhm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 8.12Q-Factor Ferrite 1.55A 70mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 4.7uH 30% 100KHz 8.12Q-Factor Ferrite 1.55A 70mOhm DCR T/R
