SRR1240-680M

BOURNS  SRR1240-680M  表面贴装功率电感器, SRR1240系列, 68 µH, ± 20%, 屏蔽, 0.2 ohm, 1.5 A

Inductor Power Shielded Wirewound 68uH 20% 100KHz 19Q-Factor Ferrite 1.5A 200mOhm DCR T/R

立创商城:
68uH ±20% 1.5A 200mΩ

得捷:
FIXED IND 68UH 1.5A 200 MOHM SMD

艾睿:
This power SRR1240-680M surface mount inductor from Bourns is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has an operating temperature range of -40 °C to 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. It has an inductance of 68u H. This product is 12.8 mm long, 4.5 mm tall and 12.8 mm deep. It has a tolerance of 20%. This SMD inductor has a maximum DC current of 1.5 A with a maximum resistance of 200m Ohm. This device utilizes wirewound technology. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 11MTyp Hz.

安富利:
Ind Power Shielded Wirewound 68uH 20% 100KHz 19Q-Factor Ferrite 1.5A T/R

Chip1Stop:
Ind Power Shielded Wirewound 68uH 20% 100KHz 19Q-Factor Ferrite 1.5A T/R

Verical:
Inductor Power Shielded Wirewound 68uH 20% 100KHz 19Q-Factor Ferrite 1.5A 200mOhm DCR T/R

Newark:
# BOURNS  SRR1240-680M  Surface Mount Power Inductor, SRR1240 Series, 68 µH, 1.5 A, 1.5 A, Shielded, 0.2 ohm

MASTER:
Inductor Power Shielded Wirewound 68uH 20% 100KHz 19Q-Factor Ferrite 1.5A 200mOhm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 68uH 20% 100KHz 19Q-Factor Ferrite 1.5A 200mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 68uH 20% 100KHz 19Q-Factor Ferrite 1.5A 200mOhm DCR T/R
