BOURNS SRR1260-150M 表面贴装功率电感器, SRR1260系列, 15 µH, ± 20%, 屏蔽, 0.027 ohm, 5 A
SRR1260 系列磁性屏蔽线绕器
Bourns SRR1260 系列贴片屏蔽式功率电感器为薄型,仅 6mm。 应用包括直流/直流转换器和电源的输入/输出,适用于:便携式通信设备;摄像机;液晶电视;汽车收音机
高电流额定值。
特别适合高频率
得捷:
FIXED IND 15UH 5A 27 MOHM SMD
欧时:
Bourns SRR1260 系列 屏蔽 铁氧体芯材 15 μH 绕线贴片电感器 SRR1260-150M, ±20%容差, 5A Idc Q:25
立创商城:
15uH ±20% 5A 27mΩ
贸泽:
Fixed Inductors 15uH 20% SMD 1260
e络盟:
# BOURNS SRR1260-150M 功率电感, 15uH, 4.6A, 20%, 17.6MHz
艾睿:
Make any circuit look clean and compact using this power SRR1260-150M surface mount inductor from Bourns. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device is made with wirewound technology. This SMD inductor has a maximum DC current of 5 A with a maximum resistance of 27m Ohm. This product is 12.8 mm long, 6.5 mm tall and 12.8 mm deep. It has an inductance of 15u H. It has a tolerance of 20%. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 17.6MTyp Hz.
Allied Electronics:
Indcutor; Power; Shielded; Wirewound; 15uH; 20%; 5A
安富利:
Ind Power Shielded Wirewound 15uH 20% 100KHz 25Q-Factor Ferrite 5A T/R
Chip1Stop:
Inductor Power Shielded Wirewound 15uH 20% 100KHz 25Q-Factor Ferrite 5A 27mOhm DCR T/R
TME:
Inductor: wire; SMD; 15uH; 5A; 27mΩ; 12.5x12.5x6mm; ±20%; -40÷125°C
Verical:
Inductor Power Shielded Wirewound 15uH 20% 100KHz 25Q-Factor Ferrite 5A 27mOhm DCR T/R
Newark:
# BOURNS SRR1260-150M Surface Mount Power Inductor, SRR1260 Series, 15 µH, 5 A, 4.6 A, Shielded, 0.027 ohm
MASTER:
Inductor Power - Shielded - Wirewound - 12.5 x 12.5 x 6mm - 15 µH - 1KHz - 5A - 27m Ohm.
Online Components:
Inductor Power Shielded Wirewound 15uH 20% 1KHz 25Q-Factor Ferrite 5A 27mOhm DCR T/R
Electro Sonic:
Inductor Power - Shielded - Wirewound - 12.5 x 12.5 x 6mm - 15 µH - 1KHz - 5A - ...
额定电流 5 A
容差 ±20 %
电感 15 µH
自谐频率 17.6 MHz
Q值 25.0
电感公差 ±20 %
测试频率 100 kHz
电阻DC) 0.027 Ω
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±20 %
电阻DC Max 0.027 Ω
安装方式 Surface Mount
引脚数 2
封装 SMD
长度 12.5 mm
宽度 12.5 mm
高度 6 mm
封装 SMD
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 工业, 便携式器材, 车用, 电源管理, 通信与网络, 消费电子产品
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
HTS代码 8504508000
香港进出口证 NLR
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SRR1260-150M Bourns J.W. Miller 伯恩斯 | 当前型号 | 当前型号 |
MSS1260-153MLD 线艺 | 功能相似 | SRR1260-150M和MSS1260-153MLD的区别 |
MSS1260T-153MLB 线艺 | 功能相似 | SRR1260-150M和MSS1260T-153MLB的区别 |
PM125SH-150M 伯恩斯 | 功能相似 | SRR1260-150M和PM125SH-150M的区别 |
