SRP1265A-1R5M

BOURNS  SRP1265A-1R5M  表面贴装功率电感器, AEC-Q200 SRP1265A系列, 1.5 µH, ± 20%, 屏蔽, 3000 µohm, 27 A

SRP1265A 系列磁性屏蔽式功率器

Bourns SRP 系列高电流电感器具有羰基粉芯且符合 AEC-Q200。

**特点和优势：**

SRP1265A 系列电感器为带羰基粉芯的屏蔽结构

高饱和电流

电感范围为 0.15 至 47μH

符合 AEC-Q200

符合 RoHS 标准且无卤

应用包括汽车系统（驾驶员辅助、信息、娱乐和照明）、直流-直流转换器和电源

立创商城:
1.5uH ±20% 27A 2.7mΩ

得捷:
FIXED IND 1.5UH 27A 3 MOHM SMD

欧时:
Bourns SRP1265A 系列 屏蔽 羰基粉芯材 1.5 μH 绕线贴片电感器 SRP1265A-1R5M, ±20%容差, 27A Idc

e络盟:
功率电感SMD, 1.5 µH, 27 A, 屏蔽, 45 A, SRP1265A 系列, 13.5mm x 12.5mm x 6.2mm

艾睿:
This power SRP1265A-1R5M surface mount inductor from Bourns is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 150 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. It has a tolerance of 20%. This device is made with wirewound technology. It has an inductance of 1.5u H. This product is 14 mm long, 6.4 mm tall and 12.8 mm deep. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 30MTyp Hz. This SMD inductor has a maximum DC current of 27 A with a maximum resistance of 3m Ohm.

Allied Electronics:
Inductor; Shielded Power; AEC-Q200; 1.5uH 20% SMT 1265

安富利:
Ind Power Shielded 1.5uH 20% 100KHz Carbonyl Powder 27A T/R

Chip1Stop:
Inductor Power Shielded Wirewound 1.5uH 20% 100KHz 20Q-Factor Carbonyl Powder 27A 3mOhm DCR Automotive T/R

Newark:
# BOURNS  SRP1265A-1R5M  Surface Mount Power Inductor, AEC-Q200 SRP1265A Series, 1.5 H, 20%, Shielded, 3000 ohm, 27 A

Online Components:
Inductor Power Shielded Wirewound 1.5uH 20% 100KHz 20Q-Factor Carbonyl Powder 27A 3mOhm DCR Automotive T/R

Electro Sonic:
Inductor Power Shielded Wirewound 1.5uH 20% 100KHz 20Q-Factor Carbonyl Powder 27A 3mOhm DCR Automotive T/R
