SRP1265A-220M

BOURNS  SRP1265A-220M  表面贴装功率电感器, AEC-Q200 SRP1265A系列, 22 µH, ± 20%, 屏蔽, 0.037 ohm, 9 A

SRP1265A 系列磁性屏蔽式功率器

Bourns SRP 系列高电流电感器具有羰基粉芯且符合 AEC-Q200。

**特点和优势：**

SRP1265A 系列电感器为带羰基粉芯的屏蔽结构

高饱和电流

电感范围为 0.15 至 47μH

符合 AEC-Q200

符合 RoHS 标准且无卤

应用包括汽车系统（驾驶员辅助、信息、娱乐和照明）、直流-直流转换器和电源

欧时:
### SRP1265A 系列磁性屏蔽式功率电感器Bourns SRP series of high current power inductors with a carbonyl powder core and are AEC-Q200 qualified.SRP1265A 系列电感器为带羰基粉芯的屏蔽结构 高饱和电流 电感范围为 0.15 至 47μH 应用包括汽车系统（驾驶员辅助、信息、娱乐和照明）、直流/直流转换器和电源 ### Bourns 非标准表面安装电感器（扼流圈）

得捷:
FIXED IND 22UH 9A 37 MOHM SMD

立创商城:
22uH ±20% 9A 32.5mΩ

e络盟:
功率电感SMD, AEC-Q200, 22 µH, 9 A, 屏蔽, 12 A, SRP1265A Series, 13.5mm x 12.5mm x 6.2mm

艾睿:
Make any circuit look clean and compact using this power SRP1265A-220M surface mount inductor from Bourns. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 150 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This product is 14 mm long, 6.4 mm tall and 12.8 mm deep. It has an inductance of 22u H. This device is made with wirewound technology. This SMD inductor has a maximum DC current of 9 A with a maximum resistance of 37m Ohm. It has a tolerance of 20%. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 6MTyp Hz.

Allied Electronics:
Inductor; Shielded Power; AEC-Q200; 22uH 20% SMT 1265

安富利:
Ind Power Shielded 22uH 20% 100KHz Carbonyl Powder 9A T/R

Chip1Stop:
Inductor Power Shielded Wirewound 22uH 20% 100KHz 20Q-Factor Carbonyl Powder 9A 37mOhm DCR Automotive T/R

Verical:
Inductor Power Shielded Wirewound 22uH 20% 100KHz 20Q-Factor Carbonyl Powder 9A 0.037Ohm DCR Automotive T/R

Newark:
# BOURNS  SRP1265A-220M  Surface Mount Power Inductor, SRP1265A Series, 22 µH, 9 A, 12 A, Shielded, 0.037 ohm

MASTER:
Inductor Power - Shielded - Wirewound - 13.5 x 12.5 x 6.2mm - 22 µH - 100KHz - 9A - 37m Ohm.

Online Components:
Inductor Power Shielded Wirewound 22uH 20% 100KHz 20Q-Factor Carbonyl Powder 9A 37mOhm DCR Automotive T/R

Electro Sonic:
Inductor Power - Shielded - Wirewound - 13.5 x 12.5 x 6.2mm - 22 µH - 100KHz - 9A - ...
