SRN5040-4R7M

BOURNS  SRN5040-4R7M  表面贴装功率电感器, SRN5040系列, 4.7 µH, ± 20%, 半屏蔽, 0.035 ohm, 3.1 A

SRN5040 系列半磁性屏蔽式功率器

SRN5040 系列具有半屏蔽结构

半屏蔽结构

电感范围：1.5 至 47 μH

额定电流：最大 3.6 A

应用：直流/直流转换器、笔记本电脑、数码摄像机、HDD、手机、电视和 LCD 显示屏

欧时:
### SRN5040 系列半磁性屏蔽式功率电感器SRN5040 系列具有半屏蔽结构 半屏蔽结构 电感范围：1.5 至 47 μH 额定电流：最大 3.6 A 应用：直流/直流转换器、笔记本电脑、数码摄像机、HDD、手机、电视和 LCD 显示屏 ### Bourns 非标准表面安装电感器（扼流圈）

得捷:
FIXED IND 4.7UH 3.1A 35 MOHM SMD

立创商城:
4.7uH ±20% 3.1A 35mΩ

e络盟:
功率电感SMD, 4.7 µH, 3.1 A, 半屏蔽, 3.3 A, SRN5040 Series, 5mm x 5mm x 4mm

艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this power SRN5040-4R7M surface mount inductor from Bourns is perfect for you! This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. It has a tolerance of 20%. This product is 5.2 mm long, 4 mm tall and 5.2 mm deep. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 27MTyp Hz. It has an inductance of 4.7u H. This SMD inductor has a maximum DC current of 3.1 A with a maximum resistance of 35m Ohm. This device is made with wirewound technology.

Allied Electronics:
SMD Semi-Shielded Power Inductor; 4.7uH3.4A 20% 5040

Chip1Stop:
Inductor Power Semi-Shielded Wirewound 4.7uH 20% 100KHz 15Q-Factor Ferrite 3.1A 35mOhm DCR 2020 T/R

Verical:
Inductor Power Semi-Shielded Wirewound 4.7uH 20% 100KHz 15Q-Factor Ferrite 3.1A 0.035Ohm DCR 2020 T/R

Newark:
# BOURNS  SRN5040-4R7M  Surface Mount Power Inductor, SRN5040 Series, 4.7 µH, 3.1 A, 3.3 A, Semishielded, 0.035 ohm

MASTER:
Inductor Power - Semi-Shielded - Wirewound - 5 x 5 x 4mm - 4.7 µH - 100KHz - 3.1A - 35m Ohm.

Online Components:
Inductor Power Semi-Shielded Wirewound 4.7uH 20% 100KHz 15Q-Factor Ferrite 3.1A 35mOhm DCR 2020 T/R

Electro Sonic:
Inductor Power - Semi-Shielded - Wirewound - 5 x 5 x 4mm - 4.7 µH - 100KHz - 3.1A - ...
