BOURNS SRF1260-330M 功率电感, 双路, 33uH, 可并联
SRF1260 系列双绕线绕扼流圈
多种应用:并联、串联、双器和变压器
磁性屏蔽、低辐射
应用包括:SEPIC 拓扑以及便携式和固定设备中的电源
欧时:
### SRF1260 系列双绕线绕扼流圈多种应用:并联、串联、双电感器和变压器 磁性屏蔽、低辐射 应用包括:SEPIC 拓扑以及便携式和固定设备中的电源 ### Bourns 非标准表面安装电感器(扼流圈)
得捷:
INDUCT ARRAY 2 COIL 33UH SMD
e络盟:
电感, 功率, 双路, 33 µH, 0.0618 ohm, 3.28 A, 12.5mm x 12.5mm x 6mm
艾睿:
This power SRF1260-330M surface mount inductor from Bourns is ideal for saving valuable space on a PCB. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. It has an inductance of 33u|132u H. This SMD inductor has a maximum DC current of 3.28|1.64 A with a maximum resistance of 61.8m|256m Ohm. Its test frequency is 100K Hz. It has a tolerance of 20%. This product is 12.5 mm long, 6.2 mm tall and 12.5 mm deep. This device is made with wirewound technology.
Allied Electronics:
SRF1260 WireWound SMDinductor w/FerriteCore, 132SERuH, 33ParalleluH +/-20%Dual
安富利:
Ind Power Shielded Wirewound 33uH/132uH 20% 100KHz Ferrite 3.28A/1.64A T/R
Verical:
Inductor Power Shielded Wirewound 33uH/132uH 20% 100KHz Ferrite 3.28A/1.64A 0.0618Ohm/0.256Ohm DCR T/R
Newark:
# BOURNS SRF1260-330M Inductor, Power, 33 µH, 20%, 0.0618 ohm, 3.28 A, 12.5mm x 12.5mm x 6mm
Online Components:
Inductor Power Shielded Wirewound 33uH/132uH 20% 100KHz Ferrite 3.28A/1.64A 61.8mOhm/256mOhm DCR T/R
Electro Sonic:
Inductor Power Shielded Wirewound 33uH/132uH 20% 100KHz Ferrite 3.28A/1.64A 61.8mOhm/256mOhm DCR T/R
额定电流 3.28 A
容差 ±20 %
电感 33 μH
自谐频率 100 kHz
共振频率 100 kHz
电感公差 ±20 %
测试频率 100 kHz
电阻DC) ≤128 mΩ
工作温度Max 125 ℃
工作温度Min -40 ℃
电阻DC Max 256 mΩ
安装方式 Surface Mount
引脚数 4
封装 12.5mm x 12.5mm x 6mm
长度 12.5 mm
宽度 12.5 mm
高度 6.2 mm
封装 12.5mm x 12.5mm x 6mm
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 车用, 电源管理, 通信与网络, 工业, 照明, 消费电子产品, 便携式器材, 计算机和计算机周边
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SRF1260-330M Bourns J.W. Miller 伯恩斯 | 当前型号 | 当前型号 |
SRF1260A-330M 伯恩斯 | 功能相似 | SRF1260-330M和SRF1260A-330M的区别 |
