单缓冲器/驱动器，具有三态输出 SINGLE BUFFER/DRIVER WITH 3-STATE OUTPUT
Leading the input to the transmission line this buffer and line driver by Texas Instruments will amplify digital and analog signals. With a 3-state output, this is power management at its best. This line driver has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This inverting device has a typical operating supply voltage of 1.8|2.5|3.3|5 V. Its minimum operating supply voltage of 1.65 V, while its maximum is 5.5 V. It has 1 channels per chip.
输出接口数 1
电路数 1
通道数 1
针脚数 5
位数 1
传送延迟时间 4.00 ns
逻辑门个数 1
输入数 1
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 1.65V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.65 V
安装方式 Surface Mount
引脚数 5
封装 SC-70-5
长度 2 mm
宽度 1.25 mm
高度 0.9 mm
封装 SC-70-5
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
SN74LVC1G240DCKT TI 德州仪器 | 当前型号 | 当前型号 |
74LVC1G240DCKRE4 德州仪器 | 完全替代 | SN74LVC1G240DCKT和74LVC1G240DCKRE4的区别 |
74LVC1G240DCKRG4 德州仪器 | 完全替代 | SN74LVC1G240DCKT和74LVC1G240DCKRG4的区别 |
SN74LVC1G240YEAR 德州仪器 | 完全替代 | SN74LVC1G240DCKT和SN74LVC1G240YEAR的区别 |
