单3输入正与或门 SINGLE 3-INPUT POSITIVE AND-OR GATE
logic gates, developed by Texas Instruments, are a great way to implement fundamental logical decisions. This gate has an operating temperature range of -40 °C to 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This device has a typical operating supply voltage of 1.8|2.5|3.3|5 V. Its minimum operating supply voltage of 1.65 V, while its maximum is 5.5 V.
电源电压DC 1.65V ~ 5.50V
输出接口数 1
输出电流 32.0 mA
电路数 1
针脚数 6
位数 1
传送延迟时间 3.40 ns
电压波节 5.00 V, 3.30 V, 2.50 V, 1.80 V
逻辑门个数 1
输入数 3
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 1.65V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.65 V
安装方式 Surface Mount
引脚数 6
封装 SOT-23-6
封装 SOT-23-6
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
SN74LVC1G0832DBVT TI 德州仪器 | 当前型号 | 当前型号 |
SN74LVC1G0832DBVR 德州仪器 | 完全替代 | SN74LVC1G0832DBVT和SN74LVC1G0832DBVR的区别 |
74LVC1G0832DBVRG4 德州仪器 | 完全替代 | SN74LVC1G0832DBVT和74LVC1G0832DBVRG4的区别 |
74LVC1G0832DBVTE4 德州仪器 | 完全替代 | SN74LVC1G0832DBVT和74LVC1G0832DBVTE4的区别 |
