TDK SLF7032T-331MR22-2PF 表面贴装功率电感器, SLF系列, 330 µH, ± 20%, 绕线, 1.67 ohm, 220 mA
固定器
得捷:
FIXED IND 330UH 220MA 2.004 OHM
立创商城:
330uH ±20% 220mA 1.67Ω
贸泽:
Fixed Inductors 330uH 1.67ohms 0.22A
e络盟:
功率电感SMD, 330 µH, 220 mA, 绕线, SLF系列, 7mm x 7mm x 3.2mm
艾睿:
Use this power SLF7032T-331MR22-2PF surface mount inductor from TDK to make any circuit look clean and compact. This SMD inductor has an operating temperature range of -40 °C to 105 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. It has a tolerance of 20%. This product is 7.2 mm long, 3.4 mm tall and 7.2 mm deep. It has an inductance of 330u H. This SMD inductor has a maximum DC current of 220m A with a maximum resistance of 2.004 Ohm. This device utilizes wirewound technology. Its test frequency is 100K Hz.
安富利:
Ind Power Shielded Wirewound 330uH 20% 100KHz 220mA T/R
Chip1Stop:
Ind Power Shielded Wirewound 330uH 20% 100KHz Ferrite 220mA T/R
Verical:
Inductor Power Shielded Wirewound 330uH 20% 100KHz Ferrite 0.22A 2.004Ohm DCR T/R
Newark:
Surface Mount Power Inductor, SLF Series, 330 H, 20%, Wirewound, 1.67 ohm, 220 mA
MASTER:
Inductor Power Shielded Wirewound 330uH 20% 100KHz Ferrite 220mA 2.004Ohm DCR T/R
Online Components:
Inductor Power Shielded Wirewound 330uH 20% 100KHz Ferrite 220mA 2.004Ohm DCR T/R
Electro Sonic:
Inductor Power Shielded Wirewound 330uH 20% 100KHz Ferrite 220mA 2.004Ohm DCR T/R
Win Source:
330μH Shielded Wirewound Inductor 220mA 2.004 Ohm Max Nonstandard
额定电流 220 mA
容差 ±20 %
电感 330 µH
产品系列 SLF
阻值偏差 ±20 %
屏蔽 Yes
电感公差 ±20 %
测试频率 100 kHz
电阻DC) ≤2.004 Ω
工作温度Max 105 ℃
工作温度Min -40 ℃
电阻DC Max 1.67 Ω
安装方式 Surface Mount
封装 7032 metric
长度 7 mm
宽度 7 mm
高度 3.2 mm
封装 7032 metric
工作温度 -40℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 1000
制造应用 Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
ECCN代码 EAR99
HTS代码 8504508000
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SLF7032T-331MR22-2PF TDK 东电化 | 当前型号 | 当前型号 |
DR73-331-R 伊顿巴斯曼 | 功能相似 | SLF7032T-331MR22-2PF和DR73-331-R的区别 |
SLF7032T-331MR22-2 东电化 | 功能相似 | SLF7032T-331MR22-2PF和SLF7032T-331MR22-2的区别 |
