SDR0604-102KL

BOURNS  SDR0604-102KL  表面贴装功率电感器, SDR0604系列, 1 mH, ± 10%, 非屏蔽, 6.8 ohm, 120 mA

SDR0604 系列线绕扼流圈

提供 E12 系列

直径小，最大仅 5.8mm

剖面 4.8mm

符合 RoHs

应用于直流/直流转换器的输入/输出以及电源

立创商城:
1mH ±10% 120mA 6.8Ω

欧时:
### SDR0604 系列线绕扼流圈提供 E12 系列 直径小，最大仅 5.8mm 剖面 4.8mm 符合 RoHs 应用于直流/直流转换器的输入/输出以及电源 ### Bourns 非标准表面安装电感器（扼流圈）

得捷:
FIXED IND 1MH 120MA 6.8 OHM SMD

e络盟:
功率电感SMD, 1 mH, 120 mA, 非屏蔽, 120 mA, SDR0604系列, 5.8mm x 5.8mm x 4.8mm

艾睿:
Is space on a PCB a limiting factor for your electronic circuit design? Then use this power SDR0604-102KL surface mount inductor from Bourns to save valuable space. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This product is 4.8 mm tall with a diameter of 5.8 mm. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 1.5M Hz. It has an inductance of 1m H. It has a tolerance of 10%. This SMD inductor has a maximum DC current of 120m A with a maximum resistance of 6.8 Ohm. This device is made with wirewound technology.

Allied Electronics:
Inductor; Power; Non-Shielded; Wirewound; 1000uH; 10%

安富利:
Ind Power Wirewound 1mH 10% 1KHz 45Q-Factor Ferrite 120mA T/R

Chip1Stop:
Inductor Power Wirewound 1mH 10% 1KHz 45Q-Factor Ferrite 120mA 6.8Ohm DCR T/R

Verical:
Inductor Power Unshielded Wirewound 1000uH 10% 1KHz 45Q-Factor Ferrite 0.12A 6.8Ohm DCR Automotive T/R

Newark:
# BOURNS  SDR0604-102KL  Surface Mount Power Inductor, SDR0604 Series, 1 mH, 120 mA, 120 mA, Unshielded, 6.8 ohm

MASTER:
Inductor Power Wirewound 1mH 10% 1KHz 45Q-Factor Ferrite 120mA 6.8Ohm DCR Automotive T/R

Online Components:
Inductor Power Wirewound 1mH 10% 1KHz 45Q-Factor Ferrite 120mA 6.8Ohm DCR Automotive T/R

Electro Sonic:
Inductor Power Wirewound 1mH 10% 1KHz 45Q-Factor Ferrite 120mA 6.8Ohm DCR Automotive T/R
