SDR1005-151KL

BOURNS  SDR1005-151KL  电感, 非屏蔽, 150uH, 1A, SMD

SDR1005 系列线绕扼流圈

提供 E6 系列

薄型，仅 5.0mm

低至 0.68μH

符合 RoHs

应用于直流/直流转换器的输入/输出以及电源

立创商城:
150uH ±10% 800mA 590mΩ

欧时:
Bourns SDR1005 系列 铁氧体芯材 150 μH 绕线贴片电感器 SDR1005-151KL, ±10%容差, 1A Idc Q:58

得捷:
FIXED IND 150UH 800MA 590MOHM SM

e络盟:
功率电感SMD, 150 µH, 800 mA, 非屏蔽, 1 A, SDR1005系列, 12.7mm x 10mm x 5mm

艾睿:
Save valuable space on a PCB with this power SDR1005-151KL surface mount inductor from Bourns. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This device is made with wirewound technology. It has an inductance of 150u H. This SMD inductor has a maximum DC current of 800m A with a maximum resistance of 590m Ohm. This product is 12.9 mm long, 5.3 mm tall and 10.2 mm deep. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 6M Hz. It has a tolerance of 10%.

Allied Electronics:
Inductor; SMT 7mm Low Profile; Power; Q Ref 30; SRF Min 6MHz; 10%; 150uH

安富利:
Ind Power Wirewound 150uH 10% 1KHz 58Q-Factor Ferrite 800mA T/R

Chip1Stop:
Inductor Power Wirewound 150uH 10% 1KHz 58Q-Factor Ferrite 800mA 590mOhm DCR T/R

Verical:
Inductor Power Wirewound 150uH 10% 1KHz 58Q-Factor Ferrite 800mA 590mOhm DCR T/R

Newark:
# BOURNS  SDR1005-151KL  Surface Mount Power Inductor, SDR1005 Series, 150 µH, 800 mA, 1 A, Unshielded, 0.59 ohm

MASTER:
Inductor Power Wirewound 150uH 10% 1KHz 58Q-Factor Ferrite 800mA 590mOhm DCR T/R

Electro Sonic:
Inductor Power Wirewound 150uH 10% 1KHz 58Q-Factor Ferrite 800mA 590mOhm DCR T/R
