KINGBRIGHT SC08-11YWA 发光二极管显示器, 7段位, 高机械强度, 黄色, 20 mA, 2.1 V, 2.6 mcd, 1, 20.32 mm
The is a 20.32mm single digit Numeric Display with white diffused lens. The yellow source device is made with gallium arsenide phosphide on gallium phosphide yellow light emitting diode.
正向电压 2.1 V
波长 588 nm
发光强度 2.6 mcd
峰值波长 590 nm
耗散功率 75 mW
功耗 75 mW
高度尺寸特征 20.3 mm
测试电流 20 mA
正向电流 20 mA
正向电压Max 2.1 V
正向电流Max 20 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 75 mW
安装方式 Through Hole
引脚数 16
封装 DIP-18
封装 DIP-18
颜色 Yellow
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Bulk
制造应用 Industrial, Imaging, Video & Vision, Clock & Timing
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2014/12/17
