SN75462PE4

DUAL外设驱动程序 DUAL PERIPHERAL DRIVERS

description

These dual peripheral drivers are functionally interchangeable with SN55451B through SN55453B and SN75451B through SN75453B peripheral drivers, but are designed for use in systems that require higher breakdown voltages than those devices can provide at the expense of slightly slower switching speeds. Typical applications include logic buffers, power drivers, relay drivers, lamp drivers, MOS drivers, line drivers, and memory drivers.

PERIPHERAL DRIVERS FOR HIGH-VOLTAGE, HIGH-CURRENT DRIVER APPLICAONS

• Characterized for Use to 300 mA

• High-Voltage Outputs

• No Output Latch-Up at 30 V After Conducting 300 mA

• Medium-Speed Switching

• Circuit Flexibility for Varied Applications and Choice of Logic Function

• TTL-Compatible Diode-Clamped Inputs

• Standard Supply Voltages

• Plastic DIP P With Copper Lead Frame for Cooler Operation and Improved Reliability

• Package Options Include Plastic Small Outline Packages, Ceramic Chip Carriers, and Standard Plastic and Ceramic 300-mil DIPs
