STA323W

2.1高效率的数字音频系统 2.1 HIGH EFFICIENCY DIGITAL AUDIO SYSTEM

Description

The is a single-chip audio system comprising digital audio processing, digital amplifier control and a DDX® power-output stage. The STA323W uses all-digital amplification to provide high-power, high-quality and high-efficiency.

The STA323W power section consists of four independent half-bridges. These can be configured, by digital control, to operate in the following modes.

Two channels, provided by two half-bridges, and a single full-bridge giving up to 2 x 10 W + 1 x 20 W of power output.

Two channels, provided by two full-bridges, giving up to 2 x 20 W of power.

A single, parallel, full-bridge channel capable of high-current operation and giving 1 x 40W output.
