SA 系列 双通道 6 V 表面贴装 压缩扩展器 - SOIC-16WB
The SA571 Compandor is a versatile low cost dual gain control circuit in which either channel may be used as a dynamic range compressor or expandor. Each channel has a full-wave rectifier to detect the average value of the signal, a linerarized temperature-compensated variable gain cell, and an operational amplifier. The SA571 is well suited for use in cellular radio and radio communications systems, modems, telephone, and satellite broadcast/receive audio systems.
Features
---
|
电源电压DC 15.0 V
无卤素状态 Halogen Free
通道数 2
针脚数 16
增益 110 dB
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 6V ~ 18V
电源电压Max 18 V
电源电压Min 6 V
安装方式 Surface Mount
引脚数 16
封装 SOIC-16
封装 SOIC-16
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 消费类音频,电信系统, Low Level Expandor − Noise Gate, High Level Limiter, Dynamic Filters
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SA571DR2G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
SA571DG 安森美 | 完全替代 | SA571DR2G和SA571DG的区别 |
SA571NG 安森美 | 完全替代 | SA571DR2G和SA571NG的区别 |
SA571DR2 安森美 | 完全替代 | SA571DR2G和SA571DR2的区别 |
