CMOS四路采样和保持放大器 CMOS Quad Sample-and-Hold Amplifier
采样和保持 IC 数据采集 16-SOIC
得捷:
IC OPAMP SAMPL/HOLD 4CIRC 16SOIC
艾睿:
Analog Devices&s; [object Object]. name sample and hold allows capturing for holding voltage of a continuous signal for a specified amount of time used in linear systems. Its typical dual supply voltage is ±5 V. This sample and hold has a minimum operating temperature of -40 °C and a maximum of 85 °C. This device comes in tube packaging. This device uses one or two power supplies.
安富利:
Sample and Hold 4-CH 11us 16-Pin SOIC N Tube
Chip1Stop:
Sample and Hold 4-CH 11us 16-Pin SOIC N Tube
Verical:
Sample and Hold 4-CH 11us 16-Pin SOIC N Tube
Win Source:
IC OPAMP SAMPLE HOLD 16SOIC
供电电流 4 mA
电路数 4
通道数 4
转换速率 4.00 V/μs
输入补偿电压 2.5 mV
输入偏置电流 500 nA
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压Max 13.2 V
电源电压Min 10.8 V
安装方式 Surface Mount
引脚数 16
封装 SOIC-16
宽度 4 mm
封装 SOIC-16
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
制造应用 数据采集
RoHS标准 Non-Compliant
含铅标准 Contains Lead
ECCN代码 EAR99
香港进出口证 NLR
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SMP04ES ADI 亚德诺 | 当前型号 | 当前型号 |
SMP04ESZ-REEL 亚德诺 | 完全替代 | SMP04ES和SMP04ESZ-REEL的区别 |
SMP04ES-REEL 亚德诺 | 完全替代 | SMP04ES和SMP04ES-REEL的区别 |
SMP04ESZ 亚德诺 | 类似代替 | SMP04ES和SMP04ESZ的区别 |
