SN74ALVC245PWR

TEXAS INSTRUMENTS  SN74ALVC245PWR  收发器, 非反相, 1.65V至3.6V, TSSOP-20

The is an octal Bus Transceiver with 3-state outputs and designed for 1.65 to 3.6V VCC operation. The SN74ALVC245 is designed for asynchronous communication between data buses. The device transmits data from the A bus to the B bus or from the B bus to the A bus, depending on the logic level at the direction-control input. The output-enable OE\ input can be used to disable the device so the buses are effectively isolated. To ensure the high-impedance state during power up or power down, OE\ should be tied to VCC through a pull-up resistor and the minimum value of the resistor is determined by the current-sinking capability of the driver.

.

3.4ns at 3.3V Propagation delay tpd

.

±24mA Output drive at 3.3V

.

Latch-up performance exceeds 250mA per JESD 17

.

Green product and no Sb/Br
