TEXAS INSTRUMENTS SN74LVCH245APWR 收发器, 非反相, 1.65V至3.6V, TSSOP-20
The SN54LVCH245A octal bus transceiver is designed for 2.7-V to 3.6-V VCC operation, and the SN74LVCH245A octal bus transceiver is designed for 1.65-V to 3.6-V VCC operation. Inputs can be driven from either 3.3-V or 5-V devices. This feature allows the use of these devices as translators in a mixed 3.3-V/5-V system environment.
得捷:
IC TXRX NON-INVERT 3.6V 20TSSOP
立创商城:
Fast 3V Logic
德州仪器TI:
Octal Bus Transceiver With 3-State Outputs
贸泽:
总线收发器 Tri-State Octal Bus
e络盟:
收发器, 74LVC245, 1.65V至3.6V, TSSOP-20
艾睿:
Bus XCVR Single 8-CH 3-ST 20-Pin TSSOP T/R
安富利:
Bus XCVR Single 8-CH 3-ST 20-Pin TSSOP T/R
Verical:
Bus XCVR Single 8-CH 3-ST 20-Pin TSSOP T/R
Newark:
# TEXAS INSTRUMENTS SN74LVCH245APWR Transceiver, 74LVC245, 1.65 V to 3.6 V, TSSOP-20
力源芯城:
具有三态输出的八路总线收发器
Win Source:
IC BUS TRANSCEIVER DUAL 20TSSOP
DeviceMart:
IC BUS TRANSCEIVER DUAL 20TSSOP
电源电压DC 2.00V ~ 3.60V
输出接口数 8
电路数 8
通道数 8
针脚数 20
位数 8
传送延迟时间 7.00 ns
电压波节 3.30 V, 2.70 V, 2.50 V, 1.80 V
输出电流驱动 -1.00 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 1.65V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 1.65 V
安装方式 Surface Mount
引脚数 20
封装 TSSOP-20
长度 6.5 mm
宽度 4.4 mm
高度 1.05 mm
封装 TSSOP-20
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
香港进出口证 NLR
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74LVCH245APWR TI 德州仪器 | 当前型号 | 当前型号 |
SN74LVCH245APW 德州仪器 | 完全替代 | SN74LVCH245APWR和SN74LVCH245APW的区别 |
SN74LVCH245APWT 德州仪器 | 完全替代 | SN74LVCH245APWR和SN74LVCH245APWT的区别 |
SN74LVCH245APWRG4 德州仪器 | 完全替代 | SN74LVCH245APWR和SN74LVCH245APWRG4的区别 |
