500mW,MM5ZxxxT1G / SZMM5ZxxxT1G 系列,ON Semiconductor表面安装外壳,SOD-523 ### Zener Diodes, ON Semiconductor
齐纳 500mW,MM5ZxxxT1G / SZMM5ZxxxT1G 系列,
表面安装外壳,SOD-523
### Zener Diodes, ON Semiconductor
欧时:
### 齐纳二极管 500mW,MM5ZxxxT1G / SZMM5ZxxxT1G 系列,ON Semiconductor表面安装外壳,SOD-523 ### Zener Diodes, ON Semiconductor
得捷:
DIODE ZENER 3.3V 200MW SOD523
贸泽:
Zener Diodes ZENER DIODE SOD523
e络盟:
单管二极管 齐纳, 3.3 V, 500 mW, SOD-523, 2 引脚, 150 °C
艾睿:
Need to operate a diode in the reverse-breakdown region? No worries, use a voltage regulator SZMM5Z3V3T1G zener diode from ON Semiconductor. Its test current is 5 mA. Its maximum power dissipation is 300 mW. Its maximum leakage current is 5 μA. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This zener diode has a minimum operating temperature of -65 °C and a maximum of 150 °C. This zener device has a nominal voltage of 3.3 V and a voltage tolerance of 6%. It is made in a single configuration.
Allied Electronics:
SZMM5Z3V3T1G Zener Diode, 3.3V 5% 500 mW SMT 2-Pin SOD-523
Chip1Stop:
Diode Zener Single 3.3V 6% 300mW Automotive 2-Pin SOD-523 T/R
Verical:
Zener Diode Single 3.3V 5% 95Ohm 500mW Automotive 2-Pin SOD-523 T/R
容差 ±6 %
针脚数 2
正向电压 900mV @100mA
耗散功率 500 mW
测试电流 5 mA
稳压值 3.3 V
正向电压Max 900mV @100mA
额定功率Max 200 mW
工作温度Max 150 ℃
工作温度Min -65 ℃
耗散功率Max 500 mW
安装方式 Surface Mount
引脚数 2
封装 SOD-523-2
长度 1.3 mm
宽度 0.9 mm
高度 0.5 mm
封装 SOD-523-2
工作温度 -65℃ ~ 150℃
温度系数 -1.75 mV/K
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Cellular phones, hand held portables, and high density PC boards, where space is at a premium.
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SZMM5Z3V3T1G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
MM5Z3V3T1G 安森美 | 类似代替 | SZMM5Z3V3T1G和MM5Z3V3T1G的区别 |
