SMBJ5359B-TP

SMB 24V 5W

Features

x Low Profile Package for Surface MountiongFlat Handling Surface for Accurate Placement

x Zener Voltage5.1Vto200V

x High Surge Current Capability

x For Available Tolerances-see Note 1

x Available on Tape and Reel see E1A std RS-481

x  Lead Free Finish/Rohs Compliant Note1 "P"Suffix designates Compliant. See ordering information

xHalogen free available upon request by adding suffix "-HF"

得捷:
DIODE ZENER 24V 5W DO214AA

立创商城:
24V 5W

艾睿:
If your circuit requires a diode to operate in the reverse breakdown region, then this SMBJ5359B-TP zener diode from Micro Commercial Components is exactly what you need. This device has a maximum regulator current of 198 mA. Its maximum power dissipation is 5000 mW. Its maximum leakage current is 0.5 μA. Its test current is 50 mA. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. It is made in a single configuration. This zener device has a nominal voltage of 24 V and a voltage tolerance of 5%. This zener diode has an operating temperature range of -55 °C to 150 °C.

Verical:
Zener Diode Single 24V 5% 3.5Ohm 5000mW 2-Pin SMB T/R

AMEYA360:
DIODE ZENER 24V 5W DO214AA

Win Source:
DIODE ZENER 24V 5W DO214AA
