SMBJ5349B-TP

SMBJ5349B-TP 编带

Features

x Low Profile Package for Surface MountiongFlat Handling Surface for Accurate Placement

x Zener Voltage5.1Vto200V

x High Surge Current Capability

x For Available Tolerances-see Note 1

x Available on Tape and Reel see E1A std RS-481

x  Lead Free Finish/Rohs Compliant Note1 "P"Suffix designates Compliant. See ordering information

xHalogen free available upon request by adding suffix "-HF"

得捷:
DIODE ZENER 12V 5W DO214AA

立创商城:
12V ±5% 5W

艾睿:
This SMBJ5349B-TP zener diode from Micro Commercial Components will allow you to run it in the reverse direction. This device has a maximum regulator current of 395 mA. Its test current is 100 mA. Its maximum leakage current is 2 μA. Its maximum power dissipation is 5000 mW. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This zener diode has an operating temperature range of -55 °C to 150 °C. This zener device has a nominal voltage of 12 V and a voltage tolerance of 5%. It is made in a single configuration.

Verical:
Zener Diode Single 12V 5% 2.5Ohm 5000mW 2-Pin SMB T/R

Win Source:
DIODE ZENER 12V 5W DO214AA / Zener Diode 12 V 5 W ±5% Surface Mount DO-214AA SMB
