高压快速开关NPN功率晶体管 High voltage fast switching NPN power transistor
- 双极 BJT - 单 NPN - 表面贴装型 SOT-223
得捷:
TRANS NPN 400V 1A SOT223
立创商城:
NPN 400V 1A
艾睿:
If your circuit&s;s specifications require a device that can handle high levels of voltage, STMicroelectronics&s; NPN STN2580 general purpose bipolar junction transistor is for you. This bipolar junction transistor&s;s maximum emitter base voltage is 9 V. Its maximum power dissipation is 1600 mW. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This bipolar junction transistor has an operating temperature range of -65 °C to 150 °C. It has a maximum collector emitter voltage of 400 V and a maximum emitter base voltage of 9 V.
安富利:
Trans GP BJT NPN 800V 1A 4-Pin SOT-223 T/R
Chip1Stop:
Trans GP BJT NPN 400V 1A 4-Pin3+Tab SOT-223 T/R
Verical:
Trans GP BJT NPN 400V 1A 1600mW 4-Pin3+Tab SOT-223 T/R
儒卓力:
**NPN SWITCH-TR.400V 1A SOT223 **
DeviceMart:
MOSF NPN 400V 1A SOT-223
针脚数 4
极性 NPN
耗散功率 1.6 W
击穿电压集电极-发射极 400 V
集电极最大允许电流 1A
最小电流放大倍数hFE 60 @250mA, 5V
额定功率Max 1.6 W
直流电流增益hFE 60
工作温度Max 150 ℃
工作温度Min -65 ℃
耗散功率Max 1600 mW
安装方式 Surface Mount
引脚数 4
封装 TO-261-4
封装 TO-261-4
工作温度 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 PB free
ECCN代码 EAR99
