SMBJ5353B-TP

SMB 16V 5W

Features

x Low Profile Package for Surface MountiongFlat Handling Surface for Accurate Placement

x Zener Voltage5.1Vto200V

x High Surge Current Capability

x For Available Tolerances-see Note 1

x Available on Tape and Reel see E1A std RS-481

x  Lead Free Finish/Rohs Compliant Note1 "P"Suffix designates Compliant. See ordering information

xHalogen free available upon request by adding suffix "-HF"

得捷:
DIODE ZENER 16V 5W DO214AA

贸泽:
Zener Diodes 5W 16V

艾睿:
If your circuit requires a diode to operate in the reverse breakdown region, then this SMBJ5353B-TP zener diode from Micro Commercial Components is exactly what you need. Its maximum leakage current is 1 μA. Its maximum power dissipation is 5000 mW. This device has a maximum regulator current of 295 mA. Its test current is 75 mA. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This zener device has a nominal voltage of 16 V and a voltage tolerance of 5%. This zener diode has a minimum operating temperature of -55 °C and a maximum of 150 °C. It is made in a single configuration.

Chip1Stop:
Diode Zener Single 16V 5% 5W 2-Pin SMB T/R

Verical:
Zener Diode Single 16V 5% 2.5Ohm 5000mW 2-Pin SMB T/R

AMEYA360:
DIODE ZENER 16V 5W DO214AA

Win Source:
DIODE ZENER 16V 5W DO214AA
