ON SEMICONDUCTOR SM36T1G TVS Diode, TVS, SM05T1G Series, Unidirectional, 36 V, 60 V, SOT-23, 3 Pins 新
ESD 保护器,On Semiconductor
立创商城:
SM36T1G
得捷:
TVS DIODE 36VWM 60VC SOT23-3
欧时:
TVS 二极管 ON Semiconductor SM36T1G 单向, 300W, 60V, 3针 SOT-23封装
贸泽:
ESD 抑制器/TVS 二极管 LOW NOISE AMPLIFIER
e络盟:
TVS二极管, SM05T1G Series, 单向, 36 V, 60 V, SOT-23, 3 引脚
艾睿:
Never worry about unexpected ESD again from implementing this tvs SM36T1G ESD protection device manufactured from ON Semiconductor. This ESD diode has a maximum ESD protection device voltage of ±15@Air Gap/±8@Contact Disc kV. This device&s;s maximum clamping voltage is 60 V. This ESD diode has an operating temperature range of -55 °C to 150 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its capacitance value is 45Typ pF. It is made in a dual common anode|single configuration.
安富利:
ESD Suppressor TVS ±15KV 3-Pin SOT-23 T/R
Chip1Stop:
ESD Suppressor TVS 36V 3-Pin SOT-23 T/R
Verical:
ESD Suppressor Diode TVS Uni-Dir/Bi-Dir 36V 3-Pin SOT-23 T/R
Newark:
# ON SEMICONDUCTOR SM36T1G TVS DIODE, 300W, 36V, UNIDIR, SOT-23
Win Source:
TVS DIODE 36VWM 60VC SOT23-3
工作电压 36 V
电容 45 pF
额定功率 300 W
击穿电压 40 V
针脚数 3
耗散功率 300 mW
钳位电压 60 V
最大反向电压(Vrrm) 36V
测试电流 1 mA
最大反向击穿电压 46.95 V
脉冲峰值功率 300 W
最小反向击穿电压 40 V
工作温度Max 150 ℃
工作温度Min -55 ℃
工作结温 -55℃ ~ 150℃
耗散功率Max 300 mW
安装方式 Surface Mount
引脚数 3
封装 SOT-23-3
长度 2.9 mm
宽度 1.3 mm
高度 1 mm
封装 SOT-23-3
工作温度 -55℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 3000
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SM36T1G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
SM36.TCT Semtech Corporation | 功能相似 | SM36T1G和SM36.TCT的区别 |
SM36 Semtech Corporation | 功能相似 | SM36T1G和SM36的区别 |
