2A 至 9A,STMicroelectronics### 二极管和整流器,STMicroelectronics
肖特基势垒,2A 至 9A,STMicroelectronics
### 二极管和整流器,STMicroelectronics
得捷:
DIODE SCHOTTKY 25V 5A DPAK
欧时:
STMicroelectronics 二极管 STPS5L25B-TR 肖特基, Io=5A, Vrev=25V, 3引脚 DPAK TO-252封装
贸泽:
Schottky Diodes & Rectifiers 5.0 Amp 25 Volt
艾睿:
Converting from AC to DC is simple when using a Schottky diode STPS5L25B-TR rectifier from STMicroelectronics. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It is made in a single configuration. This rectifier has a minimum operating temperature of -65 °C and a maximum of 150 °C. Its peak non-repetitive surge current is 75 A, while its maximum continuous forward current is 5 A.
安富利:
Diode Schottky 25V 5A 3-Pin2+Tab DPAK T/R
富昌:
单 低压差 功率 5 A 0.35 V 肖特基 整流器 表面贴装 - TO-252-3
Chip1Stop:
Diode Schottky 25V 5A 3-Pin2+Tab DPAK T/R
Verical:
Rectifier Diode Schottky 25V 5A 3-Pin2+Tab DPAK T/R
儒卓力:
**S-Diode 25V 5A 0.31V TO252-2 **
Win Source:
DIODE SCHOTTKY 25V 5A DPAK
额定电压DC 25.0 V
额定电流 5.00 A
输出电流 ≤5.00 A
正向电压 470mV @5A
极性 Standard
热阻 2.5℃/W RθJC
正向电流 5 A
最大正向浪涌电流(Ifsm) 75 A
正向电压Max 470mV @5A
正向电流Max 5 A
工作温度Max 150 ℃
工作温度Min -65 ℃
工作结温 150℃ Max
安装方式 Surface Mount
引脚数 3
封装 TO-252-3
长度 6.6 mm
宽度 6.2 mm
高度 2.4 mm
封装 TO-252-3
工作温度 150 ℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
STPS5L25B-TR ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
STPS5L25B 意法半导体 | 功能相似 | STPS5L25B-TR和STPS5L25B的区别 |
