SMAJ8.0A-TP

单向 8V 400W

400 Watt Transient Voltage Suppressors 5.0 to 440 Volts

Features

•  For Surface Mount Applications

•  Unidirectional And Bidirectional

•  Low Inductance

•   High Temp Soldering: 260°C for 10 Seconds At Terminals

•   For Bidirectional Devices Add “C” To The Suffix of The Part Number: i.e.SMAJ5.0CA for 5% Tolerance

•   UL Recognized File # E331408

•   Lead Free Finish/Rohs Compliant Note1 "P"Suffix designates Compliant. See ordering information

立创商城:
单向 Vrwm:8V 400W

得捷:
TVS DIODE 8VWM 13.6VC DO214AC

贸泽:
ESD Suppressors / TVS Diodes 8V 400 Watts

艾睿:
Micro Commercial Components&s; SMAJ8.0A-TP TVS diode is designed to protect electronic components and circuits from electrical overstress from overvoltage and electrostatic discharge. Its peak pulse power dissipation is 400Min W. This device&s;s maximum clamping voltage is 13.6 V and minimum breakdown voltage is 8.89 V. Its maximum leakage current is 50 μA. Its test current is 1 mA. This TVS diode has a minimum operating temperature of -55 °C and a maximum of 175 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery.

Chip1Stop:
Diode TVS Single Uni-Dir 8V 400W 2-Pin SMA T/R

Win Source:
TVS DIODE 8VWM 13.6VC DO214AC / 13.6V Clamp 29.4A Ipp Tvs Diode Surface Mount DO-214AC SMA
