单向 14V 400W
400 Watt Transient Voltage Suppressors 5.0 to 440 Volts
Features
• For Surface Mount Applications
• Unidirectional And Bidirectional
• Low Inductance
• High Temp Soldering: 260°C for 10 Seconds At Terminals
• For Bidirectional Devices Add “C” To The Suffix of The Part Number: i.e.SMAJ5.0CA for 5% Tolerance
• UL Recognized File # E331408
• Lead Free Finish/Rohs Compliant Note1 "P"Suffix designates Compliant. See ordering information
得捷:
TVS DIODE 14VWM 23.2VC DO214AC
立创商城:
单向 Vrwm:14V 400W
艾睿:
Protect users and systems from overvoltage conditions by equipping your electronic equipment with Micro Commercial Components&s; SMAJ14A-TP TVS diode. This device&s;s maximum clamping voltage is 23.2 V and minimum breakdown voltage is 15.6 V. Its maximum leakage current is 1 μA. Its test current is 1 mA. Its peak pulse power dissipation is 400Min W. This TVS diode has a minimum operating temperature of -55 °C and a maximum of 175 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery.
Chip1Stop:
Diode TVS Single Uni-Dir 14V 400W 2-Pin SMA T/R
Verical:
Diode TVS Single Uni-Dir 14V 400W 2-Pin SMA T/R
额定电压DC 14.0 V
额定功率 400 W
击穿电压 15.6 V
电路数 1
耗散功率 1.5 W
钳位电压 23.2 V
测试电流 1 mA
脉冲峰值功率 400 W
最小反向击穿电压 15.6 V
击穿电压 15.6 V
工作温度Max 175 ℃
工作温度Min -55 ℃
安装方式 Surface Mount
引脚数 2
封装 DO-214AC
长度 4.6 mm
宽度 2.90 mm
高度 2.44 mm
封装 DO-214AC
工作温度 -55℃ ~ 175℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SMAJ14A-TP Micro Commercial Components 美微科 | 当前型号 | 当前型号 |
CD214A-T14ALF 伯恩斯 | 功能相似 | SMAJ14A-TP和CD214A-T14ALF的区别 |
SMAJ14-TP 美微科 | 功能相似 | SMAJ14A-TP和SMAJ14-TP的区别 |
