SMAJ7.0

ESD 抑制器/TVS 二极管 400W 7V 10% Uni-Directional

12.6V 夹子 33.3A Ipp TVS - 表面贴装型 DO-214AC（SMA）

得捷:
TVS DIODE 7VWM 12.6VC DO214AC

贸泽:
ESD 抑制器/TVS 二极管 400W 7V 10% Uni-Directional

艾睿:
Protect vulnerable electronic circuits against overvoltages by equipping your device with this SMAJ7.0 TVS diode from Littelfuse. Its peak pulse power dissipation is 400 W. This device&s;s maximum clamping voltage is 12 V and minimum breakdown voltage is 7.371 V. Its test current is 10 mA. Its maximum leakage current is 200 μA. This TVS diode has an operating temperature range of -55 °C to 150 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components.

Chip1Stop:
Diode TVS Single Uni-Dir 7V 400W 2-Pin SMA T/R

TME:
Diode: transil; 400W; 8.19V; 33.3A; unidirectional; ±10%; DO214AC
