Transil™ TVS SMT 双向 600W,SMBJ 系列,STMicroelectronics### 瞬态电压抑制器,STMicroelectronics
Transil™ TVS SMT 双向 600W,SMBJ 系列,STMicroelectronics
### 瞬态电压抑制器,STMicroelectronics
得捷:
TVS DIODE 40VWM 73.6VC SMA
欧时:
TVS 二极管 STMicroelectronics SMA6J40CA-TR 双向, 600W, 73.6V, 2针 DO-214AC SMA封装
立创商城:
Vrwm:40V 600W
艾睿:
This SMA6J40CA-TR TVS diode developed by STMicroelectronics can help protect your expensive equipment and electronics. Its peak pulse power dissipation is 600 W. Its test current is 1 mA. Its maximum leakage current is 0.2 μA. This device&s;s maximum clamping voltage is 73.6 V and minimum breakdown voltage is 44.4 V. This TVS diode has an operating temperature range of -55 °C to 175 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery.
安富利:
Diode TVS Single Bi-Dir 40V 600W 2-Pin SMA T/R
富昌:
SMA6J 系列 600 W 46.7 V 双向 瞬态电压抑制器 - DO-214AC
Chip1Stop:
Diode TVS Single Bi-Dir 40V 600W 2-Pin SMA T/R
Verical:
Diode TVS Single Bi-Dir 40V 600W 2-Pin SMA T/R
儒卓力:
**TRANSIL BI 0,6KW 47V SMA **
Win Source:
TVS DIODE 40VWM 73.6VC SMA
击穿电压 46.7 V
电路数 1
耗散功率 600 W
钳位电压 73.6 V
最大反向电压(Vrrm) 40V
测试电流 1 mA
最大反向击穿电压 49.1 V
脉冲峰值功率 600 W
最小反向击穿电压 44.4 V
击穿电压 44.4 V
工作温度Max 175 ℃
工作温度Min -55 ℃
工作结温 -55℃ ~ 175℃
安装方式 Surface Mount
引脚数 2
封装 DO-214AC
长度 4.6 mm
宽度 2.9 mm
高度 2.03 mm
封装 DO-214AC
工作温度 -55℃ ~ 175℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SMA6J40CA-TR ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
SMA6T47CAY 意法半导体 | 功能相似 | SMA6J40CA-TR和SMA6T47CAY的区别 |
SMAJ40A Multicomp | 功能相似 | SMA6J40CA-TR和SMAJ40A的区别 |
