SMA6L10A

TVS SMA6L 10V 单向 13"" 卷盘

17V Clamp 35.3A Ipp Tvs Diode Surface Mount DO-221AC

立创商城:
Vrwm:10V 600W

得捷:
TVS DIODE 10VWM 17VC DO221AC

贸泽:
ESD 抑制器/TVS 二极管 600W 10V 5% Uni-Directional

艾睿:
Save yourself hassle by equipping your device with Littelfuse&s;s SMA6L10A TVS diode which will react to sudden or momentary overvoltage conditions. Its maximum leakage current is 5 μA. Its test current is 1 mA. Its peak pulse power dissipation is 600 W. This device&s;s maximum clamping voltage is 17 V and minimum breakdown voltage is 11.1 V. This TVS diode has a minimum operating temperature of -65 °C and a maximum of 150 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components.

Chip1Stop:
Diode TVS Single Uni-Dir 10V 600W 2-Pin DO-221AC T/R
