STMICROELECTRONICS STTH1512W 快速/超快功率二极管, 单, 1.2 kV, 15 A, 1.2 V, 53 ns, 150 A
整流器,10A 至 240A,STMicroelectronics
立创商城:
1.2kV 15A 53ns
得捷:
DIODE GEN PURP 1.2KV 15A DO247
欧时:
STMicroelectronics 二极管 STTH1512W 开关, Io=15A, Vrev=1200V, 105ns, 2引脚 DO-247封装
贸泽:
整流器 Ultrafast recovery 1200 V diode
e络盟:
快速/超快二极管, 1.2 kV, 15 A, 单, 1.2 V, 53 ns, 150 A
艾睿:
Switch from an AC voltage to a DC voltage using a switching diode STTH1512W rectifier from STMicroelectronics. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. Its peak non-repetitive surge current is 200 A, while its maximum continuous forward current is 15 A. This rectifier has an operating temperature range of -65 °C to 175 °C. It is made in a single configuration.
富昌:
STTH1512 系列 1200 V 15 A 105 ns 超快恢复 二极管 - DO-247
Chip1Stop:
Diode Switching 1.2KV 15A 2-Pin DO-247 Tube
Verical:
Rectifier Diode Switching 1.2KV 15A 105ns 2-Pin DO-247 Tube
Newark:
# STMICROELECTRONICS STTH1512W Fast / Ultrafast Power Diode, 1.2 kV, 15 A, Single, 1.2 V, 53 ns, 150 A
额定电压DC 1.20 kV
额定电流 15.0 A
电容 12.0 pF
输出电流 ≤15.0 A
正向电压 2.1V @15A
极性 Standard
热阻 1.3 ℃/W
反向恢复时间 53 ns
正向电流 15 A
最大正向浪涌电流(Ifsm) 150 A
正向电压Max 1.2 V
正向电流Max 15 A
工作温度Max 175 ℃
工作温度Min -65 ℃
工作结温 175℃ Max
工作结温Max 175 ℃
安装方式 Through Hole
引脚数 2
封装 DO-247-2
长度 15.75 mm
宽度 5.15 mm
高度 20.15 mm
封装 DO-247-2
产品生命周期 Active
包装方式 Tube
制造应用 工业, Power Management, Motor Drive & Control, 电机驱动与控制, Industrial, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
STTH1512W ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
DSEI60-12A IXYS Semiconductor | 功能相似 | STTH1512W和DSEI60-12A的区别 |
STTH1512G 意法半导体 | 功能相似 | STTH1512W和STTH1512G的区别 |
40EPS12PBF 威世 | 功能相似 | STTH1512W和40EPS12PBF的区别 |
