光IC传感器 INFRARED SENSORS SPEED AND POSITION
Photodetector 0.1MHz Optoschmitt 3-Pin Side Looker
Product Highlights
Side-looking plastic package
55 ° nominal acceptance angle
TTL/LSTTL/CMOS compatible
10 ohm pull-up output
Buffer or inverting logic available
High noise immunity output
Mechanically and spectrally matched to SEP8506 and SEP8706 infrared emitting diodes
得捷:
PHOTODETECTOR SCHMITT SIDE LOOK
贸泽:
光IC传感器 INFRARED SENSORS SPEED AND POSITION
艾睿:
Photodetector 0.1MHz Optoschmitt 3-Pin Side Looker
Chip1Stop:
Photodetector 0.1MHz Optoschmitt 3-Pin Side Looker
Verical:
NoPhotodetector 0.1MHz Optoschmitt 3-Pin Side Looker
MASTER:
Photodetector 0.1MHz Optoschmitt 3-Pin Side Looker
Powell:
Sensors, Infrared Sensors, Detector
Online Components:
Photodetector 0.1MHz Optoschmitt 3-Pin Side Looker
Electro Sonic:
Photodetector 0.1MHz Optoschmitt 3-Pin Side Looker
供电电流 15 mA
波长 935 nm
时钟频率 100 kHz
耗散功率 100 mW
上升时间 70 ns
下降时间 70 ns
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 7.0 VDC
安装方式 Through Hole
引脚数 3
封装 Side Looker
长度 4.45 mm
宽度 1.52 mm
高度 5.72 mm
封装 Side Looker
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Unknown
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8542390000
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SDP8614-301 Honeywell 霍尼韦尔 | 当前型号 | 当前型号 |
QSE159 飞兆/仙童 | 功能相似 | SDP8614-301和QSE159的区别 |
QSE158 飞兆/仙童 | 功能相似 | SDP8614-301和QSE158的区别 |
OPL550 TT Electronics | 功能相似 | SDP8614-301和OPL550的区别 |
