SM15T36CAY

STMICROELECTRONICS  SM15T36CAY  TVS二极管, AEC-Q369, Transil SM15T系列, 双向, 30.8 V, 64.3 V, DO-214AB, 2 引脚

Transil™ TVS SMT 单向 1500W，SMCJ 系列，STMicroelectronics

### 瞬态电压抑制器，STMicroelectronics

得捷:
TVS DIODE 30.8VWM 64.3VC SMC

立创商城:
双向 Vrwm:30.8V 1.5kW

欧时:
TVS 二极管 STMicroelectronics SM15T36CAY 双向, 1500W, 64.3V, 2针 DO-214AB SMC封装

贸泽:
ESD 抑制器/TVS 二极管 1500 W 10kW Transil 5.8V tp 70V BI

e络盟:
TVS二极管, SM15T系列, 双向, 30.8 V, 64.3 V, DO-214AB, 2 引脚

艾睿:
Get protected with this SM15T36CAY TVS diode manufactured from STMicroelectronics. Its maximum leakage current is 0.2 μA. This device&s;s maximum clamping voltage is 64.3 V and minimum breakdown voltage is 34.2 V. Its test current is 1 mA. Its peak pulse power dissipation is 1500 W. This TVS diode has a minimum operating temperature of -40 °C and a maximum of 150 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment.

安富利:
ESD Suppressor TVS 30KV 2-Pin SMC T/R

Chip1Stop:
Diode TVS Single Bi-Dir 30.8V 1.5KW Automotive 2-Pin SMC T/R

Verical:
TVS Diode Single Bi-Dir 30.8V 1.5KW Automotive 2-Pin SMC T/R

Newark:
# STMICROELECTRONICS  SM15T36CAY  Transient Voltage Suppressor, TVS, Transil SM15T Series, Bidirectional, 30.8 V, DO-214AB, 2, 34.2 V

Win Source:
TVS DIODE 30.8VWM 64.3VC SMC
