SMDJ75A

瞬态电压抑制二极管 Transient Voltage Suppression Diodes

Description

The SMDJ series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

Applications

TVS devices are ideal for the protection of I/O Interfaces, VCCbus and other vulnerable circuits used in Telecom,

Computer, Industrial and Consumer electronic applications.

得捷:
TVS DIODE 75VWM 121VC DO214AB

立创商城:
Vrwm:75V 3kW

e络盟:
TVS二极管, SMDJ Series, 单向, 75 V, 121 V, DO-214AB, 2 引脚

艾睿:
Implement surge protection with this SMDJ75A TVS diode from Littelfuse. This device&s;s maximum clamping voltage is 121 V and minimum breakdown voltage is 83.3 V. Its peak pulse power dissipation is 3000 W. Its maximum leakage current is 2 μA. Its test current is 1 mA. This TVS diode has an operating temperature range of -65 °C to 150 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components.

Chip1Stop:
Diode TVS Single Uni-Dir 75V 3KW 2-Pin SMC T/R

TME:
Diode: transil; 3kW; 87.7V; 24.8A; unidirectional; ±5%; DO214AB
