SMDJ160CA

SMDJ系列 259V 3000 W 表面贴装 双向 瞬态电压抑制二极管 DO-214AB

259V 夹子 11.6A Ipp TVS - 表面贴装型 DO-214AB（SMCJ）

得捷:
TVS DIODE 160VWM 259VC DO214AB

立创商城:
Vrwm:160V 3kW

艾睿:
Implement surge protection with this SMDJ160CA TVS diode from Littelfuse. Its test current is 1 mA. Its peak pulse power dissipation is 3000 W. This device&s;s maximum clamping voltage is 259 V and minimum breakdown voltage is 178 V. Its maximum leakage current is 2 μA. This TVS diode has a minimum operating temperature of -65 °C and a maximum of 150 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery.

Chip1Stop:
Diode TVS Single Bi-Dir 160V 3KW 2-Pin DO-214AB T/R

TME:
Diode: transil; 3kW; 187.5V; 11.6A; bidirectional; ±5%; DO214AB

Verical:
TVS Diode Single Bi-Dir 160V 3KW 2-Pin SMC T/R
