STIEC45-33AS

Transil TVS 符合 IEC 61000-4-5 标准，STMicroelectronicsSTIEC45 Transil 系列设计用于保护直流电源线路，符合 IEC 61000-4-5，可防护雷电和工业浪涌。500 A 峰值脉冲电流 24 V 至 68 V 支架电压范围 25 °C 时具有 0.2 μA 低泄漏电流 ### 瞬态电压抑制器，STMicroelectronics

Transil TVS 符合 IEC 61000-4-5 标准，STMicroelectronics

STIEC45 Transil 系列设计用于保护直流电源线路，符合 IEC 61000-4-5，可防护雷电和工业浪涌。

500 A 峰值脉冲电流

24 V 至 68 V 支架电压范围

25 °C 时具有 0.2 μA 低泄漏电流

欧时:
TVS 二极管 STMicroelectronics STIEC45-33AS 单向, 59V, 2针 SMC封装

得捷:
TVS DIODE 33VWM 59VC SMC

立创商城:
单向 Vrwm:33V

艾睿:
Surges can be a costly problem, avoid the pain and suffering by implementing this STIEC45-33AS TVS diode from STMicroelectronics. Its maximum leakage current is 0.2 μA. This device&s;s maximum clamping voltage is 59 V and minimum breakdown voltage is 36.7 V. Its test current is 1 mA. This TVS diode has an operating temperature range of -55 °C to 150 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery.

安富利:
Transient Voltage Suppressor, Unidirectional, 33V standoff, 500A, DO-214

Chip1Stop:
Diode TVS Single Uni-Dir 33V 2-Pin DO-214AB T/R

Verical:
Diode TVS Single Uni-Dir 33V 2-Pin SMC T/R

儒卓力:
**TRANSIL UNI 500A 38,6V SMC **
