STIEC45-30AS

STMICROELECTRONICS  STIEC45-30AS  TVS二极管, TVS, Transil STIEC45系列, 单向, 30 V, 55 V, DO-214AB, 2 引脚

Transil TVS 符合 IEC 61000-4-5 标准，STMicroelectronics

STIEC45 Transil 系列设计用于保护直流电源线路，符合 IEC 61000-4-5，可防护雷电和工业浪涌。

500 A 峰值脉冲电流

24 V 至 68 V 支架电压范围

25 °C 时具有 0.2 μA 低泄漏电流

### 瞬态电压抑制器，STMicroelectronics

得捷:
TVS DIODE 30VWM 55VC SMC

欧时:
### Transil TVS 符合 IEC 61000-4-5 标准，STMicroelectronicsSTIEC45 Transil 系列设计用于保护直流电源线路，符合 IEC 61000-4-5，可防护雷电和工业浪涌。500 A 峰值脉冲电流 24 V 至 68 V 支架电压范围 25 °C 时具有 0.2 μA 低泄漏电流 ### 瞬态电压抑制器，STMicroelectronics

立创商城:
单向 Vrwm:30V

e络盟:
TVS二极管, Transil STIEC45系列, 单向, 30 V, 55 V, DO-214AB, 2 引脚

艾睿:
Do not risk expensive equipment and machinery from surges with this STIEC45-30AS TVS diode from STMicroelectronics. This device&s;s maximum clamping voltage is 55 V and minimum breakdown voltage is 33.3 V. Its test current is 1 mA. Its maximum leakage current is 0.2 μA. This TVS diode has an operating temperature range of -55 °C to 150 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components.

安富利:
Transient Voltage Suppressor, Unidirectional, 30V standoff, 500A, DO-214

Chip1Stop:
ESD Suppressor 15KV 2-Pin DO-214AB T/R

Verical:
TVS Diode Single Uni-Dir 30V 2-Pin SMC T/R

Newark:
# STMICROELECTRONICS  STIEC45-30AS  Transient Voltage Suppressor, TVS, Transil STIEC45 Series, Unidirectional, 30 V, DO-214AB, 2

儒卓力:
**TVS-DIODE UNI 500A 35V SMC **
