SAC15

瞬态电压抑制二极管 Transient Voltage Suppression Diodes

Description

The SAC Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

得捷:
TVS DIODE 15VWM 23.6VC DO204AC

立创商城:
Vrwm:15V 500W

艾睿:
Surges can be a costly problem, avoid the pain and suffering by implementing this SAC15 TVS diode from Littelfuse. Its maximum leakage current is 1 μA. This device&s;s maximum clamping voltage is 23.6 V and minimum breakdown voltage is 16.7 V. Its peak pulse power dissipation is 500 W. This TVS diode has an operating temperature range of -65 °C to 175 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment.

Chip1Stop:
Diode TVS Single Uni-Dir 15V 500W 2-Pin DO-204AC T/R

Verical:
Diode TVS Single Uni-Dir 15V 500W 2-Pin DO-15 T/R
