SN65C1168ERGYR

双路差分驱动器和接收器， 【 15 kV ESD保护 DUAL DIFFERENTIAL DRIVERS AND RECEIVERS WITH 【15-kV ESD PROTECTION

The SN65C1167E and SN65C1168E consist of dual drivers and dual receivers with ±15-kV ESD Human Body Model [HBM] and ±8-kV ESD IEC61000-4-2 Air-Gap Discharge and Contact Discharge for RS-422 bus pins. The devices meet the requirements of A/EIA-422-B and ITU recommendation V.11.

The SN65C1167E combines dual 3-state differential line drivers and 3-state differential line receivers, both of which operate from a single 5-V power supply. The driver and receiver have active-high and active-low enables, respectively, which can be connected together externally to function as direction control.

SN65C1168E drivers have individual active-high enables.
