SNHVD3082EDGKG4

低功耗RS - 485收发器，可在小型MSOP- 8封装 Low-Power RS-485 Transceivers, Available in a Small MSOP-8 Package

DESCRIPON

These devices are half-duplex transceivers designed for RS–485 data bus networks. Powered by a 5–V supply, they are fully compliant with TIA/EIA-485A standard. With controlled transition times, these devices are suitable for transmitting data over long twisted-pair cables. SN65HVD3082E and

SN75HVD3082E devices are optimized for signaling rates up to 200 kbps. SN65HVD3085E is suitable for data transmission up to 1 Mbps, where as SN65HVD3088E is suitable for applications requiring signaling rates up to 20 Mbps. These devices are designed to operate with very low supply current, typically 0.3 mA, exclusive of the load. When in the inactive shutdown mode, the supply current drops to a few nanoamps, making these devices ideal for power-sensitive applications.

FEATURES

• Available in a Small MSOP-8 Package

• Meets or Exceeds the Requirements of the TIA/EIA−485A Standard

• Low Quiescent Power

– 0.3 mA Active Mode

– 1 nA Shutdown Mode

• 1/8 Unit Load—Up to 256 Nodes on a Bus

• Bus-Pin ESD Protection Up to 15 kV

• Industry-Standard SN75176 Footprint

• Failsafe Receiver Bus Open, Bus Shorted, Bus Idle

• Glitch–Free Power–Up/Down Bus Inputs and Outputs

APPLICATIONS

• Energy Meter Networks

• Motor Control

• Power Inverters

• Industrial Automation

• Building Automation Networks

• Battery-Powered Applications

• Telecommunications Equipment
