SMDAxxC Series, Bidirectional TVS Array for Protection of Four Lines300 Watts Peak Pulse Power tp = 8/20μs Transient protection for data lines to: IEC 61000-4-2 ESD ±15kV air, ±8kV contact IEC 61000-4-4 EFT 40A 5/50ns IEC 61000-4-5 Lightning 12A 8/20μs Bidirectional protection Protects four I/O lines Low leakage current ### 瞬态电压抑制器，Semtech
43V Clamp 5A 8/20µs Ipp Tvs Diode Surface Mount 8-SO
得捷:
TVS DIODE 24VWM 43VC 8-SO
欧时:
### SMDAxxC Series, Bidirectional TVS Array for Protection of Four Lines300 Watts Peak Pulse Power tp = 8/20μs Transient protection for data lines to: IEC 61000-4-2 ESD ±15kV air, ±8kV contact IEC 61000-4-4 EFT 40A 5/50ns IEC 61000-4-5 Lightning 12A 8/20μs Bidirectional protection Protects four I/O lines Low leakage current ### 瞬态电压抑制器，Semtech
立创商城:
Vrwm:24V@Max 300W
贸泽:
ESD 抑制器/TVS 二极管 24V, 7 CHAN, TVS ARRAY
艾睿:
ESD Suppressor Diode TVS Bi-Dir 24V 8-Pin SOIC N T/R
Verical:
ESD Suppressor Diode TVS Bi-Dir 24V 8-Pin SOIC N T/R
Win Source:
TVS DIODE 24VWM 43VC
工作电压 24 V
电容 50 pF
击穿电压 26.7 V
耗散功率 300 W
钳位电压 43 V
测试电流 1 mA
脉冲峰值功率 300 W
最小反向击穿电压 26.7 V
击穿电压 26.7 V
工作温度Max 125 ℃
工作温度Min -55 ℃
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
长度 5 mm
宽度 4 mm
高度 1.5 mm
封装 SOIC-8
工作温度 -55℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
