Osram Opto, 红外线 LED, 880nm, 2针 SMD PLCC 2, SFH 426
**OSRAM SIDELED Series IR LEDs**
The SIDELED package IR series of LEDs, from Semiconductors, are SMT side-looking infrared emitters. These compact IR LEDs are ideal for applications including: Infrared illumination for cameras, IR data transmission and optical sensors.
得捷:
EMITTER IR 880NM 100MA SMD
欧时:
### OSRAM SIDELED 系列红外 LEDOSRAM 光电半导体的 SIDELED 封装 IR 系列 LED 为 SMT 侧视红外发射器。 这些紧凑型 IR LED 特别适合以下应用,包括:照相机红外线照明、IR 数据传输和光学传感器。视角:±60° PLCC2 sidelooker 封装 ### 红外线 IR 发射器,OSRAM Opto Semiconductors
艾睿:
Infrared Emitter 880nm 48mW/sr Circular Right Angle Automotive 2-Pin SMD T/R
Allied Electronics:
Opto SFH 426 SIDELED IR LED, 880nm, PLCC 2 SMD package
安富利:
LED IrLED 880nm 2-Pin SMT T/R
正向电压 1.5 V
波长 880 nm
视角 120°
峰值波长 880 nm
耗散功率 180 mW
测试电流 100 mA
正向电流 100 mA
正向电压Max 3.8 V
正向电流Max 100 mA
工作温度Max 100 ℃
工作温度Min -40 ℃
耗散功率Max 180 mW
安装方式 Surface Mount
引脚数 2
封装 SMD-2
封装 SMD-2
工作温度 -40℃ ~ 100℃ TA
产品生命周期 Obsolete
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Contains Lead
