固定电感器
固定器
得捷:
FIXED IND 47UH 1.5A 120 MOHM SMD
立创商城:
47uH ±20% 100mΩ
艾睿:
This power SLF10145T-470M1R4-H surface mount inductor from TDK is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has an operating temperature range of -40 °C to 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This SMD inductor has a maximum DC current of 1.5Typ A with a maximum resistance of 120m Ohm. It has a tolerance of 20%. This device utilizes wirewound technology. This product is 10.4 mm long, 4.8 mm tall and 10.4 mm deep. It has an inductance of 47u H. Its test frequency is 1K Hz.
安富利:
SMD INDUCTORSCOILS FOR POWER LINEWOUND, MAGNETIC SHIELDED
Verical:
Inductor Power Shielded Wirewound 47uH 20% 1KHz Ferrite 1.5A 0.12Ohm DCR Automotive T/R
Electro Sonic:
Inductor Power Shielded Wirewound 47uH 20% 1KHz Ferrite 1.5A 120mOhm DCR Automotive T/R
Win Source:
47μH Shielded Wirewound Inductor 1.5A 120 mOhm Max Nonstandard
额定电流 1.5 A
容差 ±20 %
电感 47 µH
产品系列 SLF
电感公差 ±20 %
测试频率 1 kHz
电阻DC) ≤120 mΩ
工作温度Max 125 ℃
工作温度Min -40 ℃
电阻DC Max 0.12 Ω
安装方式 Surface Mount
封装 10145 metric
长度 10.1 mm
宽度 10.1 mm
高度 4.5 mm
封装 10145 metric
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 500
RoHS标准 RoHS Compliant
含铅标准 Lead Free
