SMDJ7.0A

TVS二极管产品 TVS Diode Products

Description

The SMDJ series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

Applications

TVS devices are ideal for the protection of I/O Interfaces, VCCbus and other vulnerable circuits used in Telecom,

Computer, Industrial and Consumer electronic applications.

立创商城:
Vrwm:7V 3kW

得捷:
TVS DIODE 7VWM 12VC DO214AB

艾睿:
Prevent your circuits from experiencing malfunctions from electrostatic discharge with this SMDJ7.0A TVS diode from Littelfuse. Its peak pulse power dissipation is 3000 W. This device&s;s maximum clamping voltage is 12 V and minimum breakdown voltage is 7.78 V. Its maximum leakage current is 200 μA. Its test current is 10 mA. This TVS diode has an operating temperature range of -65 °C to 150 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery.

TME:
Diode: transil; 3kW; 8.19V; 250A; unidirectional; ±5%; DO214AB

Win Source:
TVS DIODE 7VWM 12VC SMD
