TEXAS INSTRUMENTS SN74TVC3306DCUR 芯片, 电压夹, 双路, 3路输入, VSSOP-8
电压钳 IC 8-VSSOP
得捷:
IC DUAL VOLTAGE CLAMP US8
立创商城:
SN74TVC3306DCUR
德州仪器TI:
5-V dual voltage clamp
贸泽:
数字总线开关 IC DUAL VOLTAGE CLAMP
e络盟:
TEXAS INSTRUMENTS SN74TVC3306DCUR 芯片, 电压夹, 双路, 3路输入, VSSOP-8
艾睿:
If you are looking for a device to shift between voltage levels in your microprocessor-based circuit, then the SN74TVC3306DCUR level translator from Texas Instruments is for you. This level shifter has a minimum operating temperature of -40 °C and a maximum of 85 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This device has a typical operating supply voltage of 1.8|2.5|3.3 V. Its minimum operating supply voltage of 0 V, while its maximum is 5 V.
安富利:
Voltage Level Translator 8-Pin VSSOP T/R
Chip1Stop:
Voltage Level Translator 8-Pin VSSOP T/R
Verical:
Voltage Level Translator 3-CH Unidirectional 8-Pin VSSOP T/R
Newark:
# TEXAS INSTRUMENTS SN74TVC3306DCUR Voltage Clamp, Dual, 3 Input, 1.3 ns, 5 V to 0 V, VSSOP-8
Win Source:
IC DUAL VOLTAGE CLAMP US8
DeviceMart:
IC DUAL VOLTAGE CLAMP US8
电源电压DC 0.00Vmin, 5.00Vmax
通道数 3
针脚数 8
位数 2
传送延迟时间 1.40 ns
输入数 3
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压Max 5 V
电源电压Min 0 V
安装方式 Surface Mount
引脚数 8
封装 VSSOP-8
封装 VSSOP-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74TVC3306DCUR TI 德州仪器 | 当前型号 | 当前型号 |
SN74TVC3306DCURG4 德州仪器 | 完全替代 | SN74TVC3306DCUR和SN74TVC3306DCURG4的区别 |
SN74TVC3306DCURE4 德州仪器 | 完全替代 | SN74TVC3306DCUR和SN74TVC3306DCURE4的区别 |
