AC-DC Power Supply Single-OUT 4V 55A 9Pin
AC DC 转换器 输出 输入
得捷:
AC/DC CONVERTER 4V 300W
艾睿:
Ensure optimal performance of your electronic device with the use of this SWS300A4 AC to DC power supply from TDK-Lambda. It has a voltage of 4 V. This part&s;s single output can handle a current up to 55 A. This part has a minimum operating temperature of -10 °C and a maximum of 65 °C.
Allied Electronics:
Power Supply; 225W225W85265VACACDC, 115230VAC, Output 4V 55A, 225W
AMEYA360:
AC/DC CONVERTER 4V 300W
额定功率 300 W
输出接口数 1
输出电压 4 V
输出电流 55 A
隔离电压 3 kV
输入电压DC Max 370 V
输入电压DC Min 120 V
输入电压AC Max 265 V
输入电压AC Min 85 V
输出电流Max 55 A
输入电流Min 3.6 A
额定功率Max 220 W
工作温度Max 65 ℃
工作温度Min -10 ℃
输入电压 85VAC ~ 265VAC
安装方式 Chassis
引脚数 9
长度 198 mm
宽度 102 mm
高度 102 mm
工作温度 -20℃ ~ 74℃
产品生命周期 Obsolete
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
