OMRON INDUSTRIAL AUTOMATION S8VS-12024A 开关电源
DIN-Rail Mount, 100 to 240 VAC, Switching Power Supplies
Compact, DIN-rail mount power supply with LED display incorporates a maintenance forecast and run-time monitor. Ultra-compact 40 W × 95 H size 60 W model, 3-digit, 7-segment LED display shows status at a glance. Maintenance forecast monitor displays remaining life of power supply. Run-time monitor displays how long the output has been "ON". 90 W model has two outputs; one for undervoltage output and the other for either of the monitoring functions. UL, cUL, UL508, CE. Three year warranty.
频率 833 mHz
额定电流 5 A
额定功率 120 W
输出接口数 1
输出电压 24 VDC
输出电流 5 A
输出功率 120 W
隔离电压 3 kV
输入电压DC Max 370 V
输入电压DC Min 80 V
输入电压AC Max 264 v
输入电压AC Min 85 v
输出电流Max 5 A
输入电流Min 1.9 A
输出功率Max 120 W
输入电压 100VAC ~ 240VAC
安装方式 DIN Rail
引脚数 7
封装 100
长度 121.3 mm
宽度 115 mm
高度 50 mm
封装 100
重量 550 g
工作温度 -10℃ ~ 60℃
产品生命周期 Active
包装方式 Bulk
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
S8VS-12024A Omron 欧姆龙 | 当前型号 | 当前型号 |
S8VS-12024 欧姆龙 | 完全替代 | S8VS-12024A和S8VS-12024的区别 |
