双路2号线至4线解码器/多路解复用器 DUAL 2-LINE TO 4-LINE DECODERS/DEMULTIPLEXERS
解码器/多路分解器 1 x 2:4 16-TSSOP
得捷:
IC DECODER/DEMUX 1X2:4 16TSSOP
立创商城:
SN74AHC139PW
德州仪器TI:
Dual 2-Line To 4-Line Decoders / Demultiplexers
艾睿:
Choose between multiple outputs given a certain selection inputs with this SN74AHC139PW from Texas Instruments. This decoder has a minimum operating temperature of -40 °C and a maximum of 125 °C. This device comes in tube packaging. This inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 5.5 V.
安富利:
Decoder/Demultiplexer Dual 2-to-4 16-Pin TSSOP Tube
Chip1Stop:
Decoder/Demultiplexer Dual 2-to-4 16-Pin TSSOP Tube
Verical:
Decoder/Demultiplexer Dual 2-to-4 16-Pin TSSOP Tube
Newark:
# TEXAS INSTRUMENTS SN74AHC139PW Decoder / Demultiplexer, AHC Family, 4 Output, 2 V to 5.5 V, TSSOP-16
Win Source:
Decoder/Demultiplexer 1 x 2:4 16-TSSOP
DeviceMart:
IC DECODER/DEMUX 2-4LINE 16TSSOP
电源电压DC 2.00V ~ 5.50V
输出接口数 4
电压波节 5.00 V, 3.30 V
带宽 110 MHz
输出电流驱动 -1.00 mA
输入数 2
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 16
封装 TSSOP-16
封装 TSSOP-16
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SN74AHC139PW TI 德州仪器 | 当前型号 | 当前型号 |
SN74AHC139PWR 德州仪器 | 完全替代 | SN74AHC139PW和SN74AHC139PWR的区别 |
SN74AHC139PWRG4 德州仪器 | 完全替代 | SN74AHC139PW和SN74AHC139PWRG4的区别 |
