4选1数据选择器三态输出
Are you looking to organize numerous, complex electrical lines into a clean layout? Texas Instruments" multiplexer is the perfect solution for you. This multiplexer has a minimum operating temperature of 0 °C and a maximum of 70 °C. This device comes in tube packaging. It is made in a 2 x 4:1 configuration. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V.
电源电压DC 4.50V ~ 5.50V
输出接口数 2
电路数 2
位数 4
电压波节 5.00 V
带宽 75.0 MHz
输出电流驱动 -108 µA
输入数 8
工作温度Max 70 ℃
工作温度Min 0 ℃
电源电压 4.5V ~ 5.5V
安装方式 Through Hole
引脚数 16
封装 PDIP-16
长度 19.3 mm
宽度 6.35 mm
高度 4.57 mm
封装 PDIP-16
工作温度 0℃ ~ 70℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
SN74ALS253N TI 德州仪器 | 当前型号 | 当前型号 |
SN74ALS153D 德州仪器 | 完全替代 | SN74ALS253N和SN74ALS153D的区别 |
SN74ALS153DR 德州仪器 | 完全替代 | SN74ALS253N和SN74ALS153DR的区别 |
